Description
ASRock Intel ARC B580 Steel Legend 12GB OC GDDR6 Video Card
Clock: GPU / Memory
GPU Clock: 2800 MHz
Memory Clock: 19 Gbps
Key Specification
Intel® Arc™ B580 Graphics
12GB 192-bit GDDR6
Intel® Xe2-HPG Architecture
Intel® Xe Super Sampling 2 (Intel® XeSS 2)
Intel® Xe Matrix eXtentions (Intel® XMX)
Microsoft® DirectX® 12 Ultimate
2x 8-pin Power Connectors
3x DisplayPort™ 2.1, 1x HDMI™ 2.1a
Key Features
Polychrome SYNC
Triple Fan Design
Striped Ring Fan
Stylish Metal Backplate
Ultra-fit Heatpipe
Air Deflecting Fin
0dB Silent Cooling
Super Alloy Graphics Card
Graphics Engine | - Intel® Arc B580 |
Bus Standard | - PCI® Express4.0 x 8 |
DirectX | - 12 Ultimate |
OpenGL | - 4.6 |
Memory | - 12GB GDDR6 |
Engine Clock | - 2800 MHz |
Intel® XMX Engines | - 160 |
Memory Clock | - 19 Gbps |
Memory Interface | - 192-bit |
Resolution | - Digital Max Resolution: 7680 x 4320 |
Interface | - 1 x DisplayPort 2.1 (Primary, up to UHBR13.5) - 2 x DisplayPort 2.1 (Up to UHBR10) - 1 x HDMI 2.1a ![]() |
HDCP | - Yes |
Multi-view | - 4 |
Recommended PSU | - 650W |
Power Connector | - 2x 8-pin |
Accessories | - 1 x Quick Installation Guide |
Dimensions | - 298 x 131 x 51 mm, 2.6-slot |
Net Weight | - 959 g |
Additional Information
Stock Available Onehunga: |
1 |
Stock Available Wellington: |
0 |
Stock Available St Lukes: |
0 |
Stock Available Supplier: |
0 |
On Sale: |
Yes |
