Description
Cisco Nexus 93180YC-FX 48 Ports Managed Switch N9K-C93180YC-FX Overview
The Cisco Nexus 93180YC-FX Switch is a 1RU switch with latency of less than 1 microsecond that supports 3.6 Tbps of bandwidth and 1.2 bpps. The 48 downlink ports on the 93180YC-FX are capable of supporting 1-, 10-, or 25-Gbps Ethernet or as 16-, 32-Gbps Fibre Channel ports, creating a point of convergence for primary storage, compute servers, and back-end storage resources at the top of rack.
Quick Specs
Table 1 shows the Specs.
SKU | N9K-C93180YC-FX |
Ports | 48 x 1/10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports |
Downlink supported speeds | 1/10/25-Gbps Ethernet 16/32-Gbps Fibre Channel |
CPU | 6 cores |
System memory | Up to 32 GB |
SSD drive | 128 GB |
System buffer | 40 MB |
Typical power (AC/DC) | 260W |
USB ports | 1 |
RS-232 serial ports | 1 |
Product Details
Cisco N9K-C93180YC-FX provides the following features and benefits:
①Architectural Flexibility
②Architectural Flexibility
③High Scalability, Flexibility, and Security
④Intelligent Buffer Management
⑤RDME over Converged Ethernet – RoCE Support
⑥LAN and SAN Convergence
⑦Hardware and Software High Availability
⑧Purpose-Built Cisco NX-OS Software Operating System with Comprehensive, Proven Innovations
⑨Cisco Tetration Analytics Platform Support
⑩Cisco Network Assurance Engine (NAE)
Figure 1 shows the front panel of Cisco N9K-C93180YC-FX.
Note:
① | Beacon [BCN], Status [STS], and Environment [ENV] LEDs |
② | 48 10/1-Gigabit RJ45 ports |
③ | 6 40/100-Gigabit QSFP28 ports |
Figure 2 shows the rear panel of Cisco N9K-C93180YC-FX.
Note:
① | Two power supplies (one used for operations and one used for redundancy) (AC power supplies shown) with power supply slot 1 on the left and slot 2 on the right. |
② | Four fan modules with fan slot 1 on the left and fan slot 4 on the right |
③ | Management port (RJ-45 port) |
④ | Chassis LEDs (Beacon [BCN] and Status [STS]) |
⑤ | USB port |
⑥ | Console port (RS232 port) |
⑦ | Management port (SFP+ port) |
