Description
Features:
– Supercharged BE11000 Tri-Band Wi-Fi 7 Speed: Features cutting-edge Wi-Fi 7 technology, delivers speeds of 5760 Mbps on 6GHz, 4320 Mbps on 5GHz, and 688 Mbps on 2.4GHz.
– Full 2.5G Ports: Includes four 2.5G WAN/LAN ports, making it an ideal choice for future-proofing your home network, making wired data transfers as fast as takeoff.
– VPN Client & Server Support: Enables home devices to access remote VPN servers without installing VPN software, making data transmission safer.
– The latest generation of WiFi 7 technology is more than three times faster than AX3000, allowing you to be one step ahead and enjoy smooth operation in any network environment.
– Cudy APP control and Cudy Mesh support, can build up a mesh network with all your Cudy devices, and easily control all of them in your cellphone whatever you are.
Specification:
Model Version: WR11000 1.0
CPU: 1.5 GHz Quad-Core, ARM Cortex-A53
Flash / ROM: 128 MB (1 Gbit) NAND
RAM: 512 MB (4 Gbit) DDR4
6 GHz Wi-Fi Speed: 5765 Mbps
5 GHz Wi-Fi Speed: 4324 Mbps (240 MHz), 2882 Mbps (160 MHz)
2.4 GHz Wi-Fi Speed: 688 Mbps
6 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
5 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
Wi-Fi Antennas: 6 × Fixed
FEM / PA & LNA (6 GHz): 2 × High-Power
FEM / PA & LNA (5 GHz): 2 × High-Power
FEM / PA & LNA (2.4 GHz): 2 × Standard
Beamforming: True
Max Wi-Fi Range: 320 m
Wall Performance: Two wooden walls (< 10 cm / 4″); One concrete wall (< 20 cm / 7″) or two concrete walls (< 10 cm / 4″)
Ethernet Ports: 4 × 2.5G RJ45
Ethernet Configuration: 1 × WAN, 3 × LAN
LED Indicators: System, Internet, Wi-Fi, WPS
Buttons: Power On/Off, WPS, Reset
Power Method: DC
Power Input: 12V ⎓ 2A
Power Adapter Input: 100–240V~, 50/60Hz
Power Adapter Output: 12V ⎓ 2A
Max Power Consumption: 22 W
Idle Power Consumption: 12 W
Operating Temperature: 0 ℃ ~ 40 ℃
Storage Temperature: -40 ℃ ~ 70 ℃
Operating Humidity: 10% ~ 90% (non-condensing)
Storage Humidity: 5% ~ 95% (non-condensing)
Certifications: FCC, CE
Installation: Desktop, Wall-mount
Device Dimensions: 253 × 152.5 × 48.2 mm
Product Weight: 643.4 g
Package included:
1 * WR11000
1 * Power Adapter
1 * Ethernet Cable
1 * Installation Guide
