Epomaker HE68 Lite RGB Wired Mechanical Keyboard White Clear Mag Switch, 68 Key
The HE68 Lite combines Hall Effect switches with 0.01mm adjustable actuation and 5-layer sound dampening, delivering ultra-precise, creamy keystrokes for competitive gaming.
- Compact 65% 68-key Layout
- Gaming Keyboard with Hall Effect Switch（0 Dead Zone）
- 8K Polling & 128Khz Scan Rate (0.125ms Ultra-Low Latency)
- Shine-through PBT keycaps with 2-layer A-RGB backlight
- DKS & SOCD Available
Shine-Through Backlight with Special A-RGB
Dominate the virtual battlefield with the upgraded HE68 Lite gaming keyboard of shine-through PBT keycap and unique A-RGB backlight.
8,000 Hz Polling and 128,000 Scan Rate
Level up your gaming performance with smoother, more precise control, with the HE68 Lite magnetic gaming keyboard.
0.01mm Adjustable Fast Trigger with 0 Dead Zone
Unlock your gaming potential with the responsive HE68 Lite gaming keyboard that feels like an extension of your thoughts.
Snap Key (SOCD) & Macros
Experience the revolution of Snap Key (SOCD), as our HE68 Lite prioritizes your latest key press of opposite directions, ensuring every movement is executed in time without your character freezing on the spot.
Dynamic Keystroke (DKS) & MT (Mod Tap)
Rejoice in the astonishing accuracy and speed of HE68 Lite, for formidable actions in FPS, MOBA, Rhythm, and leisure games.
Compact 65% Keyboard for Mac and WIN
Game wherever you want across all your favorite platforms, with the portable HE68 Lite keyboard of versatile compatibility.
Sound-Dampened Creamy Keyboard
Experience the symphony of smooth, satisfying thocky thuds of the 5-layer sound-dampened HE68 Lite, for ultra smooth keystrokes accompanied by crystal-clear feedback without the distracting clatter of non-dampened keyboards.
Technical Specifications
Brand EPOMAKER
Model HE68 Lite
Version HE68 Lite Magnetic Keyboard, Wired Gaming Keyboard
LAYOUT 65% ANSI US Layout
Number of Keys 68 keys
Battery No Battery
Connectivity Cable Wired (USB A to USB C)
Switch Between Mac and WIN No physical switch, and HE68 Lite automatically switch to the correct OS mode.
Case Material ABS Plastic
Plate Material PC Plastic
Flex-Cut No Flex-Cut
Stabilizers Plate-Mount Stabilizer
Mounting Structure Tray-Mount
PCB Thickness 1.6mm
Sound Dampening PRO Sandwich Foam, IXPE Switch Pad, PET Sound-Enhancement Pad, Switch Socket Pad, Bottom Foam
Keycaps Profile Cherry Profile
Keycaps Material PBT Plastic,Black Red color are not shine through keycaps.
Keycaps Manufacturing Technique Double-Shot
Switch Hall Effect Switch
RGB A-RGB Technic, South-facing, per-key RGB
Polling Rate 8000Hz
Scan Rate 128Khz
Latency 0.125ms
Adjustable Travel 0.1mm to 3.4mm, per 0.01mm
SOCD (Snap Key) Yes, the HE68 Lite Keyboard supports SOCD.
DKS & MT Yes, the HE68 Lite Keyboard supports dynamic keystroke and mod tap function.
Dead-Zone HE68 Lite keyboard supports zero dead-zones, and the dead zone is adjustable between 0 to 1mm in the software.
Programmable Yes, the HE68 Lite keyboard comes with software for Windows and Mac.
Anti-Ghosting Yes, the HE68 Lite keyboard supports N-Key Rollover.
Compatibility Mac/WIN/Android
Keyboard Dimensions 32.2cm in Length, 12cm in Width, 4cm in Height.
Keyboard Weight 0.65kg
Switch Specifications
Switch Name Epomaker Clear Mag Switch
Switch Type Magnetic Hall Effect Switch
Initial Force 25gf Min
Trigger Force 37±5gf
Bottom-out Force 45gf Max
Trigger Travel Adjustable in EPOMAKER Software from 0.1mm to 3.4mm, per 0.01mm
Total Travel 3.4±0.1mm
Initial Magnetic Flux (if PCB is 1.6mm thick) 90±10Gs
End Magnetic Flux (if PCB is 1.6mm thick) 550±50Gs
Stem Material Green POM
Top Material Transparent PC
Bottom Base Material Green PA
Lubed or Not Lubed in Factory
Spring Length 18mm
Life Spans 1,000,000,000
