Description
Fortinet FG-120G 18xGE RJ45/8xGE SFP/4x10GE SFP+ Firewall
Introducing the Fortinet FortiGate-120G, an advanced network firewall designed to deliver superior protection and performance. Equipped with 18 GE RJ45 ports, 8 GE SFP slots, and 4 10GE SFP+ slots, the FG-120G provides versatile connectivity options. Its SP5 hardware acceleration supports lightning-fast processing, while the dual AC power supplies ensure reliable operation in demanding environments.
Product Features
● 18 x GE RJ45 ports including management and high availability ports
● 8 x GE SFP slots for flexible uplink options
● 4 x 10GE SFP+ slots for high-speed connectivity
● SP5 hardware acceleration for enhanced performance
● Dual AC power supplies for increased reliability
Product Applications
● Enterprise Security: Ideal for securing enterprise networks with its high port density and fast processing capabilities.
● Data Centers: Suitable for use in data centers requiring high-speed and reliable connectivity.
● Branch Office: Perfect for branch offices needing comprehensive security and connectivity solutions.
FG-120G Specifications
Hardware Specifications
Hardware Accelerated GE RJ45 Ports
16 Hardware Accelerated GE RJ45 Management / HA Ports
2 Hardware Accelerated GE SFP Slots
8 Hardware Accelerated 10 GE SFP+ FortiLink Slots (default)
4 USB Ports
1 Console (RJ45) Port
1 Internal Storage
— Trusted Platform Module (TPM)
√ Bluetooth Low Energy (BLE)
√ Signed Firmware Hardware Switch System Performance* — Enterprise Traffic Mix
— IPS Throughput
NGFW Throughput
3.1 Gbps Threat Protection Throughput2 5 System Performanee and Capacity
2.8 Gbps Firewall Throughput (1518 / 512 / 64 byte UDP packets)
39 / 39 / 28 Gbps Firewall Latency (64 byte UDP packets)
3.17 ps Firewall Throughput (Packets Per Second)
42 Mpps Concurrent Sessions (TCP)
3 M New Sessions/Second (TCP)
140 000 Firewall Policies
10 000 IPsec VPN Throughput (512 byte)
35 Gbps Gateway-to-Gateway IPsec VPN Tunnels
2000 Client-to-Gateway IPsec VPN Tunnels
16 000 SSL-VPN Throughput
1.5 Gbps Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)
500 SSL Inspection Throughput (IPS, avg. HTTPS)
3 Gbps SSL Inspection CPS (IPS, avg. HTTPS)
2100 SSL Inspection Concurrent Session (IPS, avg. HTTPS)
315 000 Application Control Throughput (HTTP 64K)
6.7 Gbps CAPWAP Throughput (HTTP 64K)
35 Gbps Virtual Domains (Default / Maximum)
10/10 Maximum Number of FortiSwitches Supported
32 Maximum Number of FortiAPs (Total / Tunnel Mode)
128/64 Maximum Number of FortiTokens
5000 High Availability Configurations
Active-Active, Active-Passive, Clustering
