Description
Fortinet FG-61F 10 x GE RJ45/2 x WAN/128GB SSD Firewall
The Fortinet FG-61F is a compact next-generation firewall designed for secure branch and mid-sized enterprise deployments. With 10 Gbps firewall throughput and 1.4 Gbps IPS performance, it delivers strong protection for converged networks across Asia, Europe, Africa, and North America. Supporting up to 700,000 concurrent sessions and 6.5 Gbps IPsec VPN throughput, this Fortinet firewall suits distributors, small integrators, and end users seeking reliable, high-density security for wired internet edge, VPN, and secure SD-branch scenarios.
FG-61F Specifications | |
Hardware Specifications | |
GE RJ45 WAN / DMZ Ports | 2/1 |
GE RJ45 Internal Ports | 5 |
GE RJ45 FortiLink Ports (Default) | 2 |
Wireless Interface | — |
USB Ports | 1 |
Console (RJ45) | 1 |
Internal Storage | — |
Trusted Platform Module | — |
Bluetooth Low Energy (BLE) | — |
Signed Firmware Hardware Switch | — |
System Performance — Enterprise Traffic Mix | |
IPS Throughput | 1.4 Gbps |
NGFW Throughput | 1 Gbps |
Threat Protection Throughput | 700 Mbps |
System Performance | |
Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 10/10/6 Gbps |
Firewall Latency (64 byte UDP packets) | 3.3 ps |
Firewall Throughput (Packets Per Second) | 9 Mpps |
Concurrent Sessions (TCP) | 700 000 |
New Sessions/Second (TCP) | 35 000 |
Firewall Policies | 2000 |
IPsec VPN Throughput (512 byte) | 6.5 Gbps |
Gateway-to-Gateway IPsec VPN Tunnels | 200 |
Client-to-Gateway IPsec VPN Tunnels | 500 |
SSL-VPN Throughput | 900 Mbps |
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 200 |
SSL Inspection Throughput (IPS, avg. HTTPS) | 630 Mbps |
SSL Inspection CPS (IPS, avg. HTTPS) | 400 |
SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 55 000 |
Application Control Throughput (HTTP 64K) | 1.8 Gbps |
CAPWAP Throughput (HTTP 64K) | 8 Gbps |
Virtual Domains (Default / Maximum) | 10/10 |
Maximum Number of FortiSwitches Supported | 24 |
Maximum Number of FortiAPs (Total / Tunnel Mode) | 64/32 |
Maximum Number of FortiTokens | 500 |
