Fortinet FG-90G 8xGE RJ45/2x10GE SFP+ Firewall
Fortinet Fortinet FG-90G - Fortinet firewall Overview
The FortiGate-90G is designed to secure the edges of your network with efficiency and precision. Boasting 8 x GE RJ45 ports along with dual 10GE RJ45/SFP+ shared media WAN ports, this compact security appliance delivers exceptional throughput and connectivity. Its robust security features safeguard against a wide range of threats, making it an ideal choice for small to medium-sized businesses seeking high-performance network security.
Product Features
● Advanced Threat Protection
● Integrated Secure SD-WAN
● Cloud Management Capabilities
● High-Speed Connectivity and Performance
● Flexible Deployment Options
Product Applications
● Secure Branch Connectivity: Utilizes secure SD-WAN technology for connecting branch offices securely and efficiently.
● Remote Work Solutions: Offers robust VPN options for secure remote access to corporate resources.
● Cloud-Based Application Security: Ensures secure and fast connectivity to cloud applications, protecting against threats in real-time.
FG-90G Specifications
Hardware Specifications
10/5/2.5/GE RJ45 or10GE/GE SFP+/ SFP Shared Media pairs
2 GE RJ45 Internal Ports
8 Wireless Interface
— USB Ports
1 Console (RJ45)
1 Internal Storage
1 Trusted Platform Module (TPM)
√ Bluetooth Low Energy (BLE)
√ Signed Firmware Hardware Switch
— System Performance* — Enterprise Traffic Mix
IPS Throughput
4.5 Gbps NGFW Throughput
2.5 Gbps Threat Protection Throughput
2.2 Gbps System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte UDP packets)
28 / 28 / 27.9 Gbps Firewall Latency (64 byte UDP packets)
3.23 ps Firewall Throughput (Packets Per Second)
41.85 Mpps Concurrent Sessions (TCP)
3 M New Sessions/Second (TCP)
124 000 Firewall Policies
5000 IPsec VPN Throughput (512 byte)
25 Gbps Gateway-to-Gateway IPsec VPN Tunnels
200 Client-to-Gateway IPsec VPN Tunnels
2500 SSL-VPN Throughput
1.4 Gbps Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)
200 SSL Inspection Throughput (IPS, avg.HTTPS)
2.6 Gbps SSL Inspection CPS (IPSr avg・ HTTPS)
1400 SSL Inspection Concurrent Session (IPS, avg. HTTPS)
300 000 Application Control Throughput (HTTP 64K)
6.7 Gbps CAPWAP Throughput (HTTP 64K)
23.6 Gbps Virtual Domains (Default / Maximum)
10/10 Maximum Number of FortiSwitches Supported
24 Maximum Number of FortiAPs (Total / Tunnel Mode)
128/64 Maximum Number of FortiTokens
500 High Availability Configurations
Active-Active, Active-Passive, Clustering
