HP Elite Mini 800 G9 i5-14500T 16GB 256GB Win11 Pro Desktop
Overview | A desktop that can travel
The HP Elite Mini 800 Desktop PC delivers the high-performance needed to develop complex presentations, crunch big numbers, and quickly create compelling content. Equipped with a powerful Intel® Processor, responsive graphics, and smart deployment options, this is the right PC for big jobs done in small spaces.
Small size. Big impact
Get breakthrough performance with the latest Intel® processor and DDR5 memory.
Protected by HP Wolf Security
HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense.
Office and home deployment
Take the HP Elite Mini 800 home with you so you can stay productive in the hybrid work world.
Help protect our shared future
At least 50 percent of all plastic used in this PC is post-consumer recycled plastic.
Features | Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP's collaboration and connectivity technology.
Powerful Intel® processor
Help speed up demanding business applications with the latest generation Intel® Core™ processors.
Fast and efficient wireless LAN
The portability of your PC and the reliability of a fast connection determines where you can work. Get a fast and reliable connection in dense wireless environments with gigabit-speed Wi-Fi 6.
HP Sure Sense
Malware is evolving rapidly and traditional antivirus can't always recognize new attacks. Protect your PC against never-before-seen attacks with HP Sure Sense, which uses deep learning AI to provide exceptional protection against advanced malware.
Protect critical security processes
Keep your critical applications and processes running even if malware tries to shut them down with the self-healing protection of HP Sure Run.
Browse confidently
Help protect your PC from websites and read only Microsoft Office and PDF attachments with embedded malware, ransomware, or viruses with hardware enforced security from HP Sure Click.
Main Specifications
Product Description | HP Elite 800 G9 – mini desktop – Core i5 i5-14500T 1.7 GHz – vPro – 16 GB – SSD 256 GB |
Type | Personal computer – mini desktop |
Platform Technology | Intel vPro Platform |
Processor | Intel Core i5 (14th Gen) i5-14500T / 1.7 GHz (, up to 4.8 GHz, (14-core) |
Cache Memory | 24 MB L3 Cache |
Cache Per Processor | 24 MB |
RAM | 16 GB (installed) / 64 GB (max) – DDR5 SDRAM |
Storage Controller | SATA/NVMe (SATA-600 / NVMe) |
Hard Drive | SSD 256 GB – PCI Express – M.2 2280 – NVM Express (NVMe) |
Optical Storage | No optical drive |
Graphics Controller | Intel UHD Graphics 770 Dynamic Video Memory Technology |
Audio Output | Stereo |
Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, 802.11ax (Wi-Fi 6E), Bluetooth Dual-Mode |
Power | (50/60 Hz) |
OS Provided | Windows 11 Pro |
Software Included | HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP DriveLock, myHP, HP Desktop Support Utilities, HP Client Security Manager Gen7, HP SureStart Gen7, HP Touchpoint Customizer, HP Easy Clean, HP Smart Support, HP Connect for Microsoft Endpoint Manager, HP SureRun Gen5, HP Sure Recover Gen5, HP Wolf Security for Business |
Dimensions (WxDxH) | 17.7 cm x 17.5 cm x 3.4 cm |
Weight | 1.42 kg |
Environmental Standards | ENERGY STAR Qualified |
Extended Specifications
General
Platform Technology | Intel vPro Platform |
---|---|
Type | Personal computer |
Product Form Factor | Mini desktop |
Built-in Devices | Speaker |
Sensors | HP Tamper Lock |
Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
Processor / Chipset
CPU | Intel Core i5 (14th Gen) i5-14500T |
---|---|
Clock Speed | 1.7 GHz (P-core) / 1.2 GHz (E-core) |
Max Turbo Speed | 4.8 GHz (P-core) / 3.4 GHz (E-core) |
Number of Cores | 14-core |
CPU Qty | 1 |
Max CPU Qty | 1 |
L2 cache | 11.5 MB |
CPU Upgradability | Upgradable |
Chipset Type | Intel Q670 |
Cache Memory
Installed Size | L3 Cache – 24 MB |
---|---|
Cache Per Processor | 24 MB |
RAM
Installed Size | 16 GB / 64 GB (max) |
---|---|
Technology | DDR5 SDRAM |
Effective Memory Speed | 5600 MHz |
Rated Memory Speed | 5600 MHz |
Form Factor | SO-DIMM 262-pin |
Slots | 2 (Total) / 0 (empty) |
Configuration Features | 2 x 8 GB |
Hard Drive
Type | SSD – M.2 2280 |
---|---|
Capacity | 1 x 256 GB |
Interface Type | PCI Express |
Features | NVM Express (NVMe) |
Storage Controller
Type | 1 x SATA/NVMe |
---|---|
Controller Interface Type | SATA-600 / NVMe |
Optical Storage
Type | No optical drive |
---|
Monitor
Monitor Type | None. |
---|
Graphics Controller
Graphics Processor | Intel UHD Graphics 770 Dynamic Video Memory Technology |
---|---|
Video Interfaces | HDMI, DisplayPort |
HDCP Compatible | Yes |
Audio Output
Sound Output Mode | Stereo |
---|---|
Max Sampling Rate | 192 kHz |
Compliant Standards | High Definition Audio |
Input Device
Type | Mouse, keyboard |
---|
Keyboard
Keyboard Name | HP 320K |
---|
Mouse
Mouse Name | HP 320M |
---|
Networking
Ethernet Controller | Intel I219-LM |
---|---|
Wireless LAN Supported | Yes |
Wireless NIC | Intel Wi-Fi 6E AX 211 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth Dual-Mode |
Remote Management Protocol | SNMP 2 |
Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2×2) |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.11d, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v |
Expansion / Connectivity
Bays | 1 (total) / 1 (free) x internal 2.5″ |
---|---|
Slots | 1 (total) / 0 (free) x M.2 Card – 2230 (for wireless module) 2 (total) / 1 (free) x M.2 Card – 2280 (for internal storage) |
Interfaces | 1 x USB-C 3.2 Gen 2×2 (1 in front) (charging) 5 x USB 3.2 Gen 2 (2 front, 3 rear) (two of them with wake functionality, one of them is charging) 1 x headphones/microphone (CTIA and OMTP headset support) 2 x DisplayPort 1.4a 1 x HDMI 1 x LAN (Gigabit Ethernet) |
Miscellaneous
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), retractable padlock loop |
---|---|
Security Slot Type | Kensington security slot |
Compliant Standards | FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1 |
Power
Device Type | Power adapter |
---|---|
Voltage Required | AC 90-264 V (50/60 Hz) |
Power Provided | 90 Watt |
Efficiency | 89% (230VAC), 88% (115VAC) |
Power Factor Correction | Yes (active) |
Operating System / Software
OS Provided | Windows 11 Pro | ||||||||
---|---|---|---|---|---|---|---|---|---|
Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure
