Meletrix Zoom75 TIGA Tri-mode RGB Hot-Swappable Wired Mechanical Keyboard - WS Black Arowana Switches, Gunmetal Gray, Cork Foam & POM, non-flex cut PCB, 81 keys

Meletrix Zoom75 TIGA RGB Wired Keyboard WS Black Gray Cork

3 Options

Crisp- Cork Sandwich

For the first time, we’re introducing the “cork sandwich,” perfect for those who prefer a board without traditional foam. This cork layer produces a crisper sound for a unique typing experience.

Soft- Poron Foam

Poron foam offers excellent durability and fatigue resistance, ensuring consistent sound performance over time. With a muted sound profile it makes it the perfect option for office use. The darker color when compared to traditional foam also offers an overall sleek look.

Standard- Classic Foam

Classic Foam tends to change the sound profile over time while offering a higher-pitched sound profile.

Force Break Design

This mod helps reduce any metallic ringing without changing the sound signature, giving you a cleaner, more stable typing experience without sacrificing structure.

4 Mounting Systems

• Elastic Bar Silicone Mounting

A next-gen solution offering balance between rigidity and elasticity.

• Split O-Ring Mounting

Adds bounce and flexibility for a softer typing experience.

• Silica Gel Particle Mounting

Helps achieve a muted, cushioned typing feel.

• Top Mount

A classic for stability and tactility.

Screwless Quick Assembly Upgrade

We’ve replaced ribbon cables with pogo pins for easier assembly. Additionally, bumpers have been added around the pogo pins to reduce damage

Upgraded Finish Treatment

We’re introducing Acustatic, a cutting-edge electrostatic spray technology that delivers vibrant colors and superior consistency. The smooth, refined surface achieved by a 220-mesh fine spray coating offers a premium feel and finish.

Versatile Design

Screen Upgrade

The new screen reduces damage risk, doubles memory, increases transfer speed fourfold, and achieves 60 fps for smooth high-resolution display.

Screen and Knob Integration

We used a scroll wheel knob to maintain a large screen while providing functionality. The screen can be swapped for badges or keycaps for more customization.

LED Upgrade

We’ve upgraded the PCB LEDs with improved wavelength, color range, and brightness. The overall lighting area is now twice as large.

Exploded View

Product Information

Layout：75%
Case Material：Aluminum(FuII CNC)
Typing angle：6.5°
Front height：17.57mm
Keyboard width：323.77mm
Case Material：Aluminum
Module Options：Screen (Default), Badge, or Key
Force Break Mod：Yes
Connection：Tri-mode
Support VlA：Yes
Catchball System: Yes
Screwless install：Yes (Except TOP Mount and Split O-ring Mount)
ESD Protection：Yes
4 mounting systems：
Top Mounting
Elastic Bar Mounting
Silica Gel Mounting
Split O-ring Mounting
Customizable options：Rear Winglets, Rear Badge, Soul Grille
PCB： 1.6mm non-flex cut PCB
ISO/ANSI Support ：Yes
Foam：Standard, Poron, or Cork Sandwich
Battery Capacity：8000mAH
Weight：3000g
