QNAP TS-464 4-Bay 8GB NAS With 4x 4TB NAS HDD Bundle

QNAP TS-464 4-Bay 8GB NAS With 4x 4TB NAS HDD Bundle

TS-464 is a compact 4-bay NAS with superior performance. Supporting up to 66 TB storage and 4 TB M.2 SSD caching* at an affordable price, the TS-464 fulfills your multitasking challenges for file management, backup, collaboration, and video conversion.

*Using four 3.5-inch 22 TB hard drives in RAID 5 and two 2 TB M.2 SSDs. Hard drives and SSD sold separately.

2.5GbE is a must!

TS-464 is as fast as a single-port 10GbE NAS with up to 589 MB/s transfer speeds by setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports.

Quad-core for multitasking

Perform additional tasks, stream more media, and have more services running with an Intel® quad-core processor optimized for multitasking.

Smooth video conversion

Built-in GPU for enhanced video conversion, allowing videos to be smoothly streamed from the NAS to mobile devices.

Upgrade to dual-port 10GbE

Futureproof your network connection by installing a PCIe dual-port 10GbE network card that delivers up to 1,647 MB/s transfer speed.

Faster USB transfer

Two USB 3.2 Gen 2 (10Gbps) ports allow faster backup to/from USB devices.

More M.2 NVMe SSDs

If two M.2 slots aren't enough, install a QM2 PCIe expansion card for more M.2 SSD slots.

2.5GbE NAS is a must in 2023

With increasing availability on switches, motherboards, and laptops, 2023 is the year of 2.5GbE. The 2.5GbE TS-464 NAS is as fast as a single-port 10GbE NAS. By setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports to unleash network potential and increase fault tolerance, TS-464 delivers up to 589 MB/s transfer speeds.

*Test environment:
NAS : TS-464 , Intel Celeron N5095 processor, 2900 MHz (4C4T) , 4GB , 4 x Seagate ST4000NC000 4TB, RAID 5, 2 x 2.5GbE, QTS 5.0.0
Client PC : Intel Xeon W-2123 3.6GHz , DDR4 32GB , Windows Server 2019
IOmeter : RAM*0.5, 5-sec ramp up time, 20-sec seq. run time, 16 workers, 4-outstanding

New-generation quad-core processor for optimized performance

Processor: Intel® Celeron® N5095 quad-core processor, burst up to 2.9 GHz

Memory: Built-in 8 GB DDR4 memory

GPU: Built-in Intel® UHD Graphics to speed up video processing and graphical computing

Encryption Engine: Features Intel® AES-NI 256 hardware-accelerated encryption to boost system performance while securing sensitive data.

Upgrade to dual-port 10GbE with a PCIe network card

With a superior hardware design, you can install a dual-port 10GbE network card QXG-10G2TB in the TS-464. Combining 10GbE networking, quad-core processor, and M.2 SSD caching, the TS-464 unleashes its full performance potential.

- Read 1647 MB/s
- Write 1632 MB/s

Expand storage capacity up to 16 hard drives

TS-464 supports a storage capacity of up to 66 TB by installing four 3.5-inch 22 TB hard drives in RAID 5. By connecting a TL-D1600S QNAP storage expansion unit, you can add an additional twelve hard drives to the TS-464 to achieve up to 280TB storage space to meet growing storage requirements.

- Storage capacity up to 66 TB

One Touch Copy backup with USB 3.2 Gen 2

TS-464 provides two 10Gbps USB 3.2 Gen 2 ports for faster file transfer to/from USB 3.2 Gen 2 devices. The One Touch Copy button also allows you to back up the contents of USB devices to the TS-464 with a single button press.

Smoother mobile experience with GPU

Taking a lot of photos with your smartphone? Qfile mobile app will help you free up space by automatically backing up photos to the TS-464. With Intel® UHD Graphics, the TS-464 greatly speeds up converting videos to 1080p / 720p, allowing for smooth streaming to mobile devices over varying mobile network speeds.

Use your NAS like a PC

QNAP's exclusive Virtualization Station enables running multiple Windows®/Linux® virtual machines. By connecting a keyboard, mouse, and HDMI monitor, you can easily use the TS-464 as a PC.

For more information: https://www.qnap.com/en/product/ts-464

IronWolf

Seagate ST4000VN006, 5,400RPM, SATA III 6Gb/s, 3.5in, 4TB capacity, AgileArray, 256MB cache, Tough, ready, and scalable. IronWolf drives are NAS-optimized for 24x7 in NAS enclosures. Tuned with AgileArray and multi-user technology, IronWolf allows you to do more with your NAS.

IronWolf provides a workload rate of 180 TB/year with scalable 24x7 performance that can handle multi-bay NAS environments, as well as capacities up to 4 TB. It fits applications like 1- to 8-bay network attached storage (NAS).

Drive health and data recovery

When integrated into compatible NAS systems, these drives provide overall system reliability increases due to IronWolf Health Management (IHM).

TS-464

CPU

Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz

CPU Architecture

64-bit x86

Graphic Processors

Intel® UHD Graphics

Floating Point Unit

Yes

Encryption Engine

Yes (AES-NI)

Hardware-accelerated Transcoding

Yes

System Memory

8 GB on board (non-expandable)

Maximum Memory

8 GB

Flash Memory

4GB (Dual boot OS protection)

Drive Bay

4 x 3.5-inch SATA 6Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/

Drive Compatibility

3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

Hot-swappable

Yes

M.2 Slot

2 x M.2 2280 PCIe Gen 3 x1

SSD Cache Acceleration Support

Yes

2.5 Gigabit Ethernet Port (2.5G/1G/100M)

2 (2.5G/1G/100M/10M)

5 Gigabit Ethernet Port (5G/2.5G/1G/100M)

Optional via PCIe expansion card

10 Gigabit Ethernet Port

Optional via PCIe expansion card

Wake on LAN (WOL)

Yes

Jumbo Frame

Yes
