StarTech RKCONS17HD Rackmount KVM Console HD 1080p 1U 17" LCD KVM Drawer with Cables


(No reviews yet) Write a Review
SKU:
KVMSTARC17HD
MPN:
RKCONS17HD
Auckland Stock:
0
Wellington Stock:
0
Stock at Supplier:
0
$2,175.00

online great rate loans from $500 with

Out of stock

Description

StarTech RKCONS17HD Rackmount KVM Console HD 1080p 17" LCD

Providing centralized control of your single PC or dozens of servers, this HD rackmount KVM console also gives you easy access to and visibility of your system while it's mounted in a server rack or cabinet. Connected to your servers through a separate KVM switch (sold separately), the LCD console installs into 1U of rack-space, offering a space-efficient solution for complete console control.



High-Definition LCD Monitor

The 1080p KVM console's monitor is 17.3" and LED back-lit, for low power consumption. It supports high-definition resolutions up to 1920x1080 providing sharper video performance. This HD console also provides more screen space, helping you to run multiple applications on the same screen, increasing your productivity.



Clutter-Free Monitoring

The rack-mount LCD console slides out from 1U of rack space, enabling you to easily monitor and control a single server or multiple servers when connected through a KVM switch. The rackmount VGA KVM features a handle that makes it easy to slide the console in and out of the server rack, keeping your area organized and clutter-free.



Simple Setup

This single-port KVM console comes with everything you need to set up:

1 Audio Cable
1 Set of KVM Cables (VGA)
2 Rear Mounting Brackets
M5 Cage Nuts and Screws



Cost Effective Solution

This KVM console provides all the essential controls you'll need to manage your server room at a low cost. The console features a built-in keyboard and a touchpad for intuitive control, as well as a high-definition LCD display.

StarTech.com offers a wide selection of KVM consoles to help you access your systems more efficiently without the expense and clutter of extra peripherals.

Connector(s)
Host ConnectorsHD15 (15 pin, High Density D-Sub) Female Input
Other Interface(s)IEC 60320 C14 Power Female Input
Environmental
Humidity10 ~ 80% RH
Operating Temperature0°C to 40°C (32°F to 104°F)
Storage Temperature-20°C to 60°C (-4°F to 140°F)
Hardware
AudioNo
Cables IncludedYes
Daisy-ChainNo
Display Size17.3"
KVM Ports1
Number of Monitors Supported1
Panel TypeActive Matrix TFT LCD
PC InterfaceUSB
PC Video TypeVGA
Rack-MountableYes
U Height1U
Indicators
LED IndicatorsPower / Status LED
Packaging Information
Package Height18.5 cm [7.3 in]
Package Length76.5 cm [30.1 in]
Package Width61.5 cm [24.2 in]
Shipping (Package) Weight16 kg [35.4 lb]
Performance
Aspect Ratio16:9
Brightness300 cd/m²
Color Depth6-bit, 262144 colors
Contrast Ratio800:1
IP ControlNo
Maximum Analog Resolutions1920x1080
Maximum Number of Users1
MTBF50000 Hours
Pixel Pitch Support0.1989 x 0.1989 mm
Supported ResolutionsResolutions up to 1920x1080 @ 60Hz
Viewing Angle170° (H), 170° (V)
Physical Characteristics
Cable Length1.8 m
ColorBlack
Enclosure TypeSteel
Maximum Mounting Depth85 cm [33.5 in]
Minimum Mounting Depth510 mm [20.1 in]
Product Height4.3 cm [1.7 in]
Product Length56.5 cm [22.2 in]
Product Width48.3 cm [19 in]
Weight of Product13.7 kg [30.3 lb]
Power
Input Current1.5A
Input Voltage100 - 240 AC
Power Consumption (In Watts)13W
Power SourceInternational Power Cords
Prominence
Description CDW 75 - 1st LineStarTech.com 17" HD Rackmount KVM Console - 1 Port VGA -1080p
What's in the Box
Included in PackageKVM cable
 KVM console
 M5 cage nuts
 M5 screws
 mounting rails
 quick-start guide
 regional power cords (NA, JP, UK, EU, ANZ)
