Description
Device Protection
PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable™, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.
Convenient Wall-Mounting
The 24V, 0.5A models, POE-24-12W and POE-24-12W-G, are wall-mountable using the optional wall-mount brackets.
Seamless airGateway™ Compatibility
The 15V, 0.8A and 24V, 0.5A models, POE-15-12W, POE-24-12W and POE-24-12W-G, work with the airGateway™ to bridge airMAX® connections to Wi-Fi at customer locations.
Details | |
---|---|
Manufacturer's Product Code | POE-24-24W-5P-AU |
Dimensions | 88 x 57 x 33 mm |
Weight | 135 g |
Output Voltage | 24VDC @ 1.0A |
LAN Activity Indicator | No |
Gigabit LAN Port | No |
Remote Reset Capability | Yes |
Reset Button | Yes |
Rated Voltage | 100-240VAC @ 50/60Hz |
Input Current | 0.6A @ 120VAC, 0.4A @ 240VAC |
Inrush Current | <60A Peak @ 120VAC, <120A Peak @ 230VAC |
Efficiency | 80+% |
Output Ripple | 1% Max. |
Switching Frequency | 65 kHz |
Line Regulation | = 3% |
Load Regulation | = 5% |
2-Pair Powering | Pins 4, 5 (+) and Pins 7, 8 (-)) |
4-Pair Powering | No |
Operating Temperature | 0 to 40° C (32 to 104° F) |
Storage Temperature | -30 to 70°C (-22 to 158° F) |
Operating Humidity | 35 to 95% Noncondensing |
AC Connector | IEC-320 C6 |
Data IN / POE | RJ45 Shielded Socket |
Surge Protection | Difference and Common Mode |
Clamping Protection | 11V Data, 60V Power |
Max. Surge Discharge | 1500A (8/20 µs) Power |
Peak Pulse Current | 36A (10/1000 µs) Data |
Shunt Capacitance | <5 pF data |
Response Time | <1 ns |
Certifications | CE, FCC, IC, UL |
