Description
SUNANY WD116 11.6" IPS LCD Non-Touch Customer Display
1. Features an IPS panel with 350 nits brightness, delivering clear visuals and wide viewing angles
2. Supports VESA 75×75 and 100×100 international mounting standards, suitable for various mounting environments
Specifications
| Specification | Details |
|---|---|
| Model | WD116 |
| Screen Size | 11.6" |
| Display Technology | IPS |
| Backlight Brightness | 350 cd/m² (350 nits) |
| Aspect Ratio | 16:9 |
| Resolution | 1366 × 768 (HD) |
| Active Display Area | 256.13 (H) × 144 (V) mm |
| Contrast Ratio | 800:1 |
| Display Colours | 262K Colours |
| Colour Gamut | 55% |
| Response Time | 25ms |
| VESA Mounting | 75 × 75mm / 100 × 100mm |
| Power Supply | DC 5V |
| Operating Temperature | -10°C to +45°C |
| Storage Temperature | -20°C to +60°C |
| Operating Humidity | 35%–70% RH |
| Storage Humidity | 20%–70% RH |
