Description
A compact and powerful UniFi gateway with a full suite of advanced routing and security features.
- Up to 10x routing performance increase over USG (tested with IPS/IDS, QoS, and Smart Queues)
- Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
- (1) GbE WAN port
- (1) GbE LAN port
- Compact footprint
- USB-C powered (adapter included)
- Managed with UniFi Network 8.0.7 and later
Mechanical
Dimensions
98 x 98 x 30 mm (3.9 x 3.9 x 1.2")
Weight
320 g (11.3 oz)
Enclosure material
Polycarbonate
Hardware
Processor
Dual-core ARM® Cortex®-A53 at 1 GHz
Memory information
1 GB DDR3L
Management interface
Ethernet
Bluetooth 5.1
Networking interface
LAN:
(1) GbE RJ45 port
WAN:
(1) GbE RJ45 port
Power method
USB type C (5V/3A)
Supported voltage range
100-240V
Max. power consumption
3.83W
Ambient operating temperature
-10 to 40° C (14 to 104° F)
Ambient operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Gateway Features
Performance
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Internet quality and outage reporting
Next-generation security
Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall
Advanced networking
License-free SD-WAN*
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport* and Identity Enterprise VPN**
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IPv6 ISP support
Application Requirements
UniFi Network
Version 8.0.7 and later
